DRIVE UNITS (PER SPEAKER)
Uni-Q driver array:
HF: 19 mm (0.75in.) aluminium dome
LF/MF: 115 mm (4.5in.) magnesium/aluminium alloy cone
FREQUENCY RANGE (-6dB) MEASURED AT 85 dB / 1M
49 Hz – 47 kHz
FREQUENCY RESPONSE (±3dB) MEASURED AT 85 dB / 1 M
54 Hz – 28 kHz
AMPLIFIER OUTPUT POWER (PER SPEAKER)
LF: 70 W
HF: 30 W
AMPLIFIER CLASS (PER SPEAKER)
LF: Class D
HF: Class D
MAX SPL MEASURED AT 1 M
102 dB
WIRELESS STREAMING FEATURES
AirPlay 2
Google Chromecast
Roon Ready
UPnP Compatible
Bluetooth 5.0
Plays with Audirvāna
STREAMING SERVICES
Spotify via Spotify Connect
Tidal via Tidal Connect
Amazon Music
Qobuz
Deezer
QQ Music via QPlay
Internet Radio
Podcast
SOURCE RESOLUTION
Network up to 384 kHz / 24 bit
Optical up to 96 kHz / 24 bit
USB Type C up to 192 kHz / 24 bit
HDMI up to 1.411 Mbps PCM
INTERSPEAKER CONNECTION
Wireless: all sources resampled to 48 kHz / 24 bit PCM
Wired: all sources resampled to 96 kHz /24 bit PCM
SUPPORTED FORMAT (NETWORK)
MQA^, DSD, FLAC, WAV, AIFF, ALAC, AAC, WMA, MP3, M4A, LPCM and Ogg Vorbis
HOME AUTOMATION SYSTEM
Elan, RTi, Crestron Home, Savant, Control4
INPUTS
Primary speaker
HDMI ARC
TOSLINK Optical
USB Type C
Analog 3.5mm Auxiliary
RJ45 Ethernet (network)
RJ45 Ethernet (interspeaker)
Secondary speaker
RJ45 Ethernet (interspeaker)
OUTPUT
RCA Subwoofer output
WI-FI NETWORK STANDARD
IEEE 802.11a/b/g/n/ac
IPv4, IPv6
WI-FI NETWORK FREQUENCY BAND
Dual-band 2.4 GHz / 5 GHz
|
